[EXA] MOXA BiDi SFP-1G10ALC BLC 10km ±¤¸ðµâ¼¼Æ®
MOXA BiDi ¼¼Æ®(2°³: SFP-1G10ALC + SFP-1G10BLC), 1.25Gb/s, 1¡¿Fibre Channel, 10Km LC BiDi SFP Transceiver,Single LC, +3.3V,( 1310,1490,1550nm Tx/1550,1490,1310,nm Rx), FP-LD, Single-mode, DDM
ÆÇ¸Å°¡°Ý 210,000 ¿ø
¸ðµ¨¸í EXA-1G-54D10-WAB-MOX
Á¦Á¶¿ø EXA OPTICS
¿ø»êÁö Çѱ¹/ ´ë¸¸ µî
Àç°í ÆÇ¸ÅÁß
±¸¸Å¼ö·® EA

[EXA] MOXA 1000Base BiDi SFP-1G10ALC BLC ¼¼Æ®, 10km, ½Ì±Û¸ðµå, ȣȯ ±¤¸ðµâ

PART NO: EXA-1G-54D10-WAB-MOX

MOXA





MOXA BiDi ¼¼Æ®(2°³: SFP-1G10ALC + SFP-1G10BLC),
1.25Gb/s, 1¡¿Fibre Channel, 10Km LC BiDi SFP Transceiver,Single LC, +3.3V,( 1310,1490,1550nm Tx/1550,1490,1310,nm Rx), FP-LD, Single-mode, DDM

Features:

©÷  Up to 1.25Gb/s Data Links

©÷  Hot-Pluggable

©÷  Single LC connector

©÷  Up to 10 km on 9/125¥ìm SMF

©÷  1310,1490,1550nm FP laser transmitter

©÷  1490,1310,1310nm PIN photo-detector

©÷  Single +3.3V Power Supply

©÷  Monitoring Interface Compliant with SFF-8472

©÷  Maximum power dissipation <1W

©÷  Industrial /Extended/ Commercial operating temperature range: -40¡ÆC to 85¡ÆC/-5¡ÆC to 85¡ÆC/-0¡ÆC to 70¡ÆC Version available

©÷  RoHS compliant and Lead Free



Applications:

©÷  1000Base-LX Ethernet

©÷  Metro/Access Networks

©÷  1¡¿Fibre Channel

©÷  Other Optical Links



Description:

EXA-1G-54D10-WAB Transceivers are a high performance, cost effective module which have a single LC optics interface. They are compatible with the Small Form Factor Pluggable Multi-Sourcing Agreement (MSA) and Digital diagnostics functions are available via the 2-wire serial bus specified in SFF-8472. The receiver section uses a PIN receiver and the transmitter uses a 1310 ,1490,1550nm FP laser, up to 14dB link budge ensure this module 1000Base-LX Ethernet 10km application.




*¿ÜÇüÀº º¯°æµÉ ¼öÀÖ½À´Ï´Ù
